The GlobTek DR6SM3100USBA-USBA is an enclosed DC DC converter designed for ITE commercial applications. It operates with an input voltage range of 12-24 Vdc and provides a stable 5.0V output at 3.1A, delivering a total power of 15.5W.
This converter features integrated Type "A" USB sockets that are compliant with the USB Battery Charging Specification Revision 1.2 (BC 1.2), enabling efficient charging of compatible devices. The unit has a chassis mount type and measures 63.7mm in length, 47.8mm in width, and 18.1mm in height.
It is designed for a wide operating temperature range of -20°C to 45°C, with derating applied. The DR6SM3100USBA-USBA is suitable for applications requiring a reliable and compact DC DC power conversion solution with USB charging capabilities.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The DR6SM3100USBA-USBA provides a 5.0V output at 3.1A.
The total power output of the DR6SM3100USBA-USBA is 15.5W.
The converter supports an input voltage range of 12-24 Vdc.
Yes, it features integrated Type "A" USB sockets compliant with USB Battery Charging Specification Revision 1.2 (BC 1.2).
The dimensions are 63.7mm in length, 47.8mm in width, and 18.1mm in height.
The operating temperature range is -20°C to 45°C, with derating.
It uses a chassis mount type.
