| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9 pcs
|
9 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Shielding | |
| Tape & Reel | |
| Tolerance | |
| Type | |
| Width |
This Eaton DR1030-220-R is a fixed inductor designed for various electronic applications. It features a drum core and wirewound construction, providing a shielded design for reduced electromagnetic interference.
The inductor offers a nominal inductance of 22 µH with a tolerance of ±30%. It is rated for a current of 1.8A and has a maximum DC resistance of 114.6 mOhm. The component is designed for surface mounting and has dimensions of 10.50mm in length, 10.30mm in width, and 3.00mm in height.
Operating within a temperature range of -40°C to 125°C, this inductor is suitable for demanding environments. The material used is ferrite, contributing to its magnetic properties. Compliance information indicates RoHS3 compliance, MSL 1, and REACH unaffected status, though these are unverified.
This part is identified by its part number DR1030-220-R and is manufactured by Eaton. It is categorized under Fixed Inductors.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.56 | $0.56 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 22 µH.
The current rating is 1.8A.
The maximum DC resistance is 114.6mOhm.
It operates between -40°C and 125°C.
It is a surface mount component.
It is a drum core, wirewound, shielded fixed inductor.
