DPS090130UPS-P5P-SZ The CUI Inc. DPS090130UPS-P5P-SZ is an AC/DC wall mount adapter providing 5V at 12W. It features a NEMA 1-15P input and a 2.1mm x 5.5mm barrel plug output.
Mfr Part #:

DPS090130UPS-P5P-SZ

Mfr Name: CUI Inc.
CUI Inc.
The CUI Inc. DPS090130UPS-P5P-SZ is an AC/DC wall mount adapter providing 5V at 12W. It features a NEMA 1-15P input and a 2.1mm x 5.5mm barrel plug output.
Stock on Request

DPS090130UPS-P5P-SZ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Cord Length
Current
Efficiency
Form
Height
Input Connector
Input Type
Length
Operating Temperature
Output Connector
Polarization
Power (Watts)
Region Utilized
Voltage
Width
View Similar Products (0)

DPS090130UPS-P5P-SZ Description

Short technical summary and product information.

This AC/DC wall mount adapter from CUI Inc., part number DPS090130UPS-P5P-SZ, is designed for ITE (Commercial) applications. It delivers a stable 5V output with a maximum power of 12W and an output current of 2A. The adapter utilizes a NEMA 1-15P input connector suitable for North American regions and a standard 2.1mm I.D. x 5.5mm O.D. barrel plug output with a positive center polarization.



The unit operates within a temperature range of 0°C to 40°C and has an efficiency rating of 60%. Its dimensions are 60.0mm in length, 44.0mm in width, and 25.0mm in height, making it a compact wall-mount solution. The adapter is classified as Class II and comes with a 72-inch (1.83m) cord length. It is RoHS3 compliant and has an MSL of 1.

DPS090130UPS-P5P-SZ Quick Information

Product Type: AC DC Desktop, Wall Adapter
Canonical Name: AC/DC WALL MOUNT ADAPTER 5V 12W
Subcategory: AC DC Desktop, Wall Adapter

DPS090130UPS-P5P-SZ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

DPS090130UPS-P5P-SZ Features

  • AC/DC wall mount adapter with 5V output.
  • 12W maximum power and 2A current.
  • NEMA 1-15P input for North America.
  • 2.1mm x 5.5mm barrel plug output.
  • Compact dimensions: 60.0mm x 44.0mm x 25.0mm.

DPS090130UPS-P5P-SZ Applications

  • Suitable for ITE commercial applications.
  • Designed for North American power outlets.
  • Ideal for devices requiring 5V DC power.
  • Compact form factor for easy integration.

DPS090130UPS-P5P-SZ FAQs

5 frequently asked questions generated from this part’s specifications.
What is the output voltage and power of the DPS090130UPS-P5P-SZ adapter?

The DPS090130UPS-P5P-SZ adapter has an output voltage of 5V and a maximum power of 12W.

What type of input connector does the DPS090130UPS-P5P-SZ use?

The DPS090130UPS-P5P-SZ uses a NEMA 1-15P input connector.

What are the dimensions of the DPS090130UPS-P5P-SZ adapter?

The dimensions of the DPS090130UPS-P5P-SZ adapter are 60.0mm in length, 44.0mm in width, and 25.0mm in height.

What is the operating temperature range for the DPS090130UPS-P5P-SZ adapter?

The operating temperature range for the DPS090130UPS-P5P-SZ adapter is 0°C to 40°C.

Is the DPS090130UPS-P5P-SZ adapter RoHS compliant?

The DPS090130UPS-P5P-SZ adapter is RoHS3 compliant.
