DP83847ALQA56A/NOPB The Texas Instruments DP83847ALQA56A/NOPB is a single 10/100 Mbps Ethernet transceiver supporting 10BASE-T and 100BASE-TX protocols. It features an MII interface and operates at 3.3V.
Mfr Part #:

DP83847ALQA56A/NOPB

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments DP83847ALQA56A/NOPB is a single 10/100 Mbps Ethernet transceiver supporting 10BASE-T and 100BASE-TX protocols. It features an MII interface and operates at 3.3V.
✓ Total Stock: 12,981 pcs
$ Price Range: $4.53

DP83847ALQA56A/NOPB Available from 3 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

DP83847ALQA56A/NOPB Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Data Rate
Lead Spacing
Mounting Type
Number of Drivers
Number of Ports
Operating Temperature
Power Consumption
Protocol
Supplier Device Package
Supplier Package
Type
Voltage
Voltage Supply
View Similar Products (0)

DP83847ALQA56A/NOPB Description

Short technical summary and product information.

The DP83847ALQA56A/NOPB from Texas Instruments is a single-chip Physical Layer (PHY) device designed for 10/100 Mbps Ethernet applications. It integrates the PMD sublayers to support both 10BASE-T and 100BASE-TX Ethernet protocols over Category 3 or Category 5 unshielded twisted pair cables.



This transceiver interfaces directly to MAC devices via the IEEE 802.3u standard Media Independent Interface (MII). It utilizes on-chip Digital Signal Processing (DSP) technology and digital Phase Lock Loops (PLLs) for robust performance and enhanced noise immunity. Key features include low-power 3.3V CMOS technology, 5V tolerant I/Os, and IEEE 802.3 compliant Auto-Negotiation.



The device is supplied in a 56-WQFN (9x9 mm) surface mount package. It operates within a temperature range of 0°C to 70°C and requires a supply voltage of 3V to 3.6V. The DP83847ALQA56A/NOPB is suitable for applications such as LAN on Motherboard and embedded systems.

DP83847ALQA56A/NOPB Quick Information

Product Type: Ethernet Transceiver
Canonical Name: DP83847ALQA56A/NOPB Single 10/100 Ethernet Transceiver
Subcategory: Ethernet PHY

DP83847ALQA56A/NOPB Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

DP83847ALQA56A/NOPB Estimated Pricing

Qty Low High
1+ $4.53 $4.53

Estimated market price range - modelled values for guidance only, not live distributor offers.

DP83847ALQA56A/NOPB Features

  • Single 10/100 Mbps Ethernet transceiver.
  • Supports 10BASE-T and 100BASE-TX protocols.
  • MII interface for MAC connectivity.
  • Low-power 3.3V CMOS technology.
  • Surface mount 56-WQFN package.

DP83847ALQA56A/NOPB Applications

  • Ideal for LAN on Motherboard.
  • Suitable for embedded applications.
  • Facilitates 10/100 Mb/s Ethernet solutions.
  • Designed for home and office networks.

DP83847ALQA56A/NOPB FAQs

5 frequently asked questions generated from this part’s specifications.
What data rates does the DP83847ALQA56A/NOPB support?

The DP83847ALQA56A/NOPB supports 10/100 Mbps data rates.

What interface type does this Ethernet transceiver use?

This Ethernet transceiver uses the MII interface type.

What is the operating voltage for the DP83847ALQA56A/NOPB?

The operating voltage for this device is 3.3V.

What is the operating temperature range?

The operating temperature range is 0°C to 70°C.

What package is the DP83847ALQA56A/NOPB supplied in?

It is supplied in a 56-WQFN Exposed Pad package.
