| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
250 pcs
|
250 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Core Material | |
| Current Rating | |
| Current Saturation | |
| DC Resistance | |
| Inductance | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Self Resonant Frequency | |
| Shielding | |
| Tape & Reel | |
| Tolerance |
The Coilcraft DO1608C-333MLC is a wirewound fixed inductor designed for various electronic applications. It offers an inductance value of 33µH with a tolerance of ±20% and a maximum DC resistance of 510mΩ. The inductor is rated for a continuous current of 800mA and a saturation current of 580mA.
This component features an unshielded ferrite core and is constructed using wirewound technology. It operates within a temperature range of -40°C to 85°C. The self-resonant frequency is 15MHz, and the inductance is tested at 100kHz.
The DO1608C-333MLC is designed for surface mounting, making it suitable for compact PCB designs. It is packaged in Tape & Reel (TR) format. The nonstandard package case indicates specific dimensions that should be referenced from the manufacturer's documentation.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.19 | $0.19 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
33 µH.
800 mA.
510 mOhm maximum.
15 MHz.
Nonstandard surface mount package, supplied in tape and reel.
-40°C to +85°C.
No, it is unshielded.
