DMN2016LHAB-7 Dual N-Channel Enhancement Mode MOSFET, 20V drain-source voltage, 7.5A continuous drain current, 15.5mOhm typical on-resistance, in a 6-UDFN surface mount package.
Mfr Part #:

DMN2016LHAB-7

Available from 2 distributors
Mfr Name: Diodes Incorporated
Diodes Incorporated
Dual N-Channel Enhancement Mode MOSFET, 20V drain-source voltage, 7.5A continuous drain current, 15.5mOhm typical on-resistance, in a 6-UDFN surface mount package.
✓ Total Stock: 3,296 pcs

DMN2016LHAB-7 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
2,363 pcs
On Request
2363 pcs On Request 1 On Request On Request 18+ On Request On Request
Rayichip ✓
Non-Authorised Inventory information
933 pcs
On Request
933 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

DMN2016LHAB-7 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Configuration
Current
Drain to Source Voltage (Vdss)
FET Feature
Gate Charge (Qg) (Max) @ Vgs
Halogen Free
Input Capacitance (Ciss) (Max) @ Vds
Mounting Type
Operating Temperature
Power
Rds On (Max) @ Id, Vgs
Supplier Device Package
Technology
Vgs(th) (Max) @ Id
View Similar Products (0)

DMN2016LHAB-7 Description

Short technical summary and product information.

The DMN2016LHAB-7 is a dual N-channel enhancement mode MOSFET from Diodes Incorporated, designed for high-efficiency power management applications. It features two common-drain N-channel MOSFETs in a compact 6-pin U-DFN2030-6 exposed pad package.



Key electrical ratings include a maximum drain-to-source voltage of 20V and a continuous drain current of 7.5A at 25°C (5.8A at 70°C). The device offers low on-resistance down to 15.5mOhm at Vgs=4.5V, with logic-level gate drive capability (Vgs(th) max 1.1V). Pulsed drain current can reach 45A, and gate charge is 16nC.



The MOSFET is surface-mountable with a lead-free, halogen-free green molding compound. It is rated for operation from -55°C to +150°C junction temperature and has a moisture sensitivity level of 1 per J-STD-020. Typical applications include power management functions, battery packs, and load switches.

DMN2016LHAB-7 Quick Information

Product Type: MOSFET Array
Canonical Name: DUAL N-CHANNEL ENHANCEMENT MODE MOSFET
Subcategory: Dual N-Channel Common Drain

DMN2016LHAB-7 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Lead Free

DMN2016LHAB-7 Features

  • Dual N-channel common-drain MOSFET.
  • 20V drain-to-source voltage rating.
  • 7.5A continuous drain current at 25°C.
  • Low 15.5mOhm on-resistance at 4.5V.
  • Logic-level gate threshold voltage.

DMN2016LHAB-7 Applications

  • Ideal for power management functions.
  • Used in battery pack protection circuits.
  • Suitable for load switch applications.

DMN2016LHAB-7 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum drain-to-source voltage (Vdss) of the DMN2016LHAB-7?

20 V.

What is the maximum continuous drain current at 25°C?

7.5 A (with Vgs=4.5V).

What is the on-resistance (Rds on) at 4.5V gate drive?

Maximum 15.5 mOhm at Id=4A, Vgs=4.5V.

What package does the DMN2016LHAB-7 come in?

6-UDFN Exposed Pad (supplier package U-DFN2030-6 Type B).

What is the operating temperature range?

-55°C to 150°C (junction temperature).

Is the DMN2016LHAB-7 RoHS compliant?

Yes, the datasheet states it is totally lead-free and fully RoHS compliant.

What is the gate threshold voltage?

Maximum 1.1 V at Id=250µA.
