DLPC200ZEW The Texas Instruments DLPC200ZEW is a digital controller designed for the DLP5500 DMD. It offers XGA resolution and supports high-speed pattern rates.
Mfr Part #:

DLPC200ZEW

Available from 1 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments DLPC200ZEW is a digital controller designed for the DLP5500 DMD. It offers XGA resolution and supports high-speed pattern rates.
✓ Total Stock: 2,356 pcs
$ Price Range: $231.00

DLPC200ZEW Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
2,356 pcs
On Request
2356 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

DLPC200ZEW Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Mounting Type
Operating Temperature Range
SVHC Present
Supplier Device Package
Type
View Similar Products (0)

DLPC200ZEW Description

Short technical summary and product information.

The Texas Instruments DLPC200ZEW is an active DLP® controller specifically designed to drive the DLP5500 digital micromirror device (DMD). This controller is essential for applications requiring reliable, high-speed micromirror control, including structured light, display, and other spatial light modulation (SLM) applications.



Key technical specifications include a maximum display resolution of XGA (1024x768) and an operating temperature range of -20°C to 85°C. It supports high-speed pattern sequences with binary patterns up to 5000 Hz and 8-bit grayscale patterns up to 700 Hz. The device features two 24-bit input ports, with Port 1 supporting HDMI input and Port 2 supporting input via an expansion card.



Multiple configuration interfaces are available, including I2C, USB, and SPI, offering flexibility for external and embedded input sources. It also provides three configurable output triggers and two configurable input triggers for easy synchronization with external devices like cameras and sensors, enabling applications such as 3D machine vision.



The DLPC200ZEW is housed in a 780-BGA package and is designed for surface mounting. Its ability to stream data in real-time and download pattern data directly to the device makes it ideal for advanced light control applications.

DLPC200ZEW Quick Information

Product Type: Digital Controller
Series: DLPC200
Canonical Name: DLPC200ZEW DLP® controller for DLP5500 digital micromirror device (DMD)
Subcategory: DLP Controllers & Drivers

DLPC200ZEW Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

DLPC200ZEW Estimated Pricing

Qty Low High
1+ $231.00 $231.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

DLPC200ZEW Features

  • DLP controller for DLP5500 DMD.
  • XGA resolution up to 1024x768.
  • High-speed pattern rates up to 5000 Hz.
  • Wide operating temperature range: -20 to 85°C.
  • Surface mount 780-BGA package.

DLPC200ZEW Applications

  • Ideal for structured light applications.
  • Used in display and projection systems.
  • Enables 3D machine vision applications.
  • Supports spatial light modulation (SLM).
  • Facilitates advanced light control.

DLPC200ZEW FAQs

6 frequently asked questions generated from this part’s specifications.
What is the maximum display resolution supported by the DLPC200ZEW?

The maximum display resolution supported is XGA (1024x768).

What is the operating temperature range for the DLPC200ZEW?

The operating temperature range is -20 to 85 °C.

What are the pattern rates for the DLPC200ZEW?

It supports 1-bit binary pattern rates up to 5000 Hz and 8-bit grayscale pattern rates up to 700 Hz.

What type of input ports does the DLPC200ZEW have?

It has two 24-bit input ports, with Port 1 supporting HDMI input and Port 2 supporting input via an expansion card.

What configuration interfaces are available on the DLPC200ZEW?

Available configuration interfaces include I2C, USB, and SPI.

How is the DLPC200ZEW mounted?

The DLPC200ZEW is a surface mount device.
