The NexTek DLP-GBE-BTI is an indoor lightning and transient surge protector specifically designed to protect sensitive end points in IEEE 802.3at Gigabit Ethernet systems. It effectively diverts lightning energy coupled onto CAT5/6 data cables, whether in common or differential modes, safely to ground using internal transient protection circuitry. This device is normally passive, activating only under excessive transient conditions.
Key electrical specifications include a data rate of 1000 Mbps per IEEE 802.3at, an impedance of 100 Ω nominal, and a DC resistance of 8 Ω. It offers multiple strike capability and pure surge protection on all pins. The maximum one-time surge current is rated at 300A (10/1000µS waveform) and 5kA (8/20µS waveform). Repetitive surge current handling is 100A (10/1000µS) and 3kA (8/20µS).
Featuring a rugged and lightweight design, the DLP-GBE-BTI utilizes an RJ45 shielded jack connector. It operates within a temperature range of -40 to +65° C and supports 0 to 100% relative humidity (condensing). The device is panel mountable and weighs 3.7 oz. It is RoHS compliant and NEBS Level 3 compliant.
Applications for this surge protector include remote radio heads (RRH), PoE equipment, telco backhaul, wireless IP security cameras, internet service providers (ISPs), point-to-point radios, enterprise networks, and wireless LAN access points and bridges.
-40 to +65°C.
1000 Mbps (1000 Base-T per IEEE 802.3at).
300A for 10/1000µS waveform per Telcordia GR-1089 and 5kA for 8/20µS waveform per IEC 61000-4-5.
Line-Line <100V peak, Line-Ground <50V peak at 100A 10/1000µS and 3kA 8/20µS.
Panel mount.
100 Ω nominal.
Wireless applications.
