| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Height | |
| Input Voltage Min | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
The Cosel DHS100A05 is a 100W isolated DC-DC converter designed for distributed power systems. It provides a single 5V output at 20A with an efficiency of 85% typical. The input voltage range is 60-160V DC, making it suitable for a variety of industrial and commercial power architectures.
This converter features overcurrent, overvoltage, and thermal protection circuits, along with remote ON/OFF capability. The output voltage can be adjusted via external resistor or voltage, offering flexibility in system design. The module is housed in a compact 6-DIP through-hole package measuring 58.4mm x 37.3mm x 12.7mm, ideal for space-constrained board layouts.
With an operating temperature range of -40°C to 100°C (with derating), the DHS100A05 can withstand harsh environments. It is certified to UL60950-1, C-UL, and EN62368-1 safety standards, and complies with RoHS and REACH regulations. The module is intended for ITE (commercial) applications and carries a 5-year warranty.
5V DC.
20A.
85% typical.
6-DIP Module with through-hole mounting.
-40°C to 100°C (with derating).
Yes, RoHS3 Compliant.
60V DC.
