| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,050 pcs
|
4050 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Circuit | |
| Current Rating (Amps) | |
| Differential Travel | |
| Ingress Protection | |
| Mounting Type | |
| Operating Force | |
| Operating Temperature | |
| Overtravel | |
| Pretravel | |
| Switch Function | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating |
The ZF Electronics DG13-B1LA is a snap action limit switch with SPDT (Single Pole Double Throw) circuitry. It is rated for a current of 3A AC and 2A DC at 125V AC. The switch operates within a temperature range of -25°C to 85°C and features a straight lever actuator.
Designed for through-hole mounting, this limit switch utilizes PC pin termination for secure connections. Key mechanical specifications include a pretravel of 0.071" (1.8mm), an overtravel of 0.022" (0.55mm), and a differential travel of 0.020" (0.5mm). The operating force required is 45gf. The ingress protection rating is IP40.
This component is suitable for applications requiring reliable switching under specified environmental and electrical conditions. Its construction and specifications make it a component for various industrial and electronic control systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
-25°C to 85°C
SPDT
125 V
Through Hole
IP40
