| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Current Rating (Maximum @ 16 AWG) | |
| Current Rating (Maximum @ 18 AWG) | |
| Current Rating (Maximum @ 20 AWG) | |
| Current Rating (Maximum @ 22 AWG) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The DF63-2P-3.96DSA is a wire-to-board connector from Hirose's DF63 series, designed for internal power supply applications. It is a 2-position, single-row, through-hole header with a 3.96mm pitch. The connector features a shrouded 4-wall design that provides protection and prevents incorrect mating. It includes a latch holder for secure mating and a board guide for alignment. The header is rated for up to 15A when using 16 AWG wire, with lower ratings for smaller gauges. The operating temperature range is -55°C to 105°C. The insulation is black PBT glass-filled with UL94 V-0 flammability rating. Contacts are brass with tin finish. The termination is solder. This connector is suitable for potting up to 5mm and has a molded lance design to prevent tangled wires. It is RoHS3 and REACH compliant.
2 positions.
3.96mm (0.156 inches).
Up to 15A with 16 AWG wire; 13A with 18 AWG; 11A with 20 AWG; 9A with 22 AWG.
600VAC/DC.
Through-hole.
-55°C to 105°C.
Tin.
