| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The DF3DZ-10P-2V(51) is a 10-position, single-row, male pin header from Hirose Electric. It is designed for surface mount soldering with a 2.00mm pitch. The connector features a shrouded 4-wall design (push-pull fastening) and solder retention for reliable mechanical connection. The contacts are made of phosphor bronze with gold plating, rated for 3A current. The insulation is beige polyamide (PA) nylon with UL94 V-0 flammability rating. Operating temperature range is -30°C to 85°C. This header is suitable for board-to-board or cable-to-board applications. It is RoHS3 and REACH compliant, with MSL 1 (unlimited).
10 positions.
2.00mm (0.079 inches).
3A per contact.
Surface mount (SMT).
-30°C to 85°C.
Yes, it is RoHS3 compliant.
Polyamide (PA) Nylon with UL94 V-0 flammability rating.
