| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7,337 pcs
|
7337 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request | |
|
280 pcs
|
280 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The Hirose Electric DF13A-2P-1.25H(51) is a 2-position male pin header from the DF13A series. It features a 1.25mm pitch with a single row of contacts, designed for surface mount right-angle mounting to enable low-profile board-to-cable connections. The shrouded 4-wall design provides robust mating alignment and protection for the contacts.
Key specifications include a current rating of 1A and a voltage rating of 150V, with an operating temperature range of -35°C to 85°C. The contacts are made of brass with a gold finish of 8µin (0.203µm) for reliable electrical performance. The insulator is beige polyamide (nylon) rated UL94 V-0 for flammability.
This connector incorporates a detent lock fastening system for secure mating and includes solder retention features to enhance board-level reliability during assembly. The contact shape is square, and all positions are loaded. This header is suitable for wire-to-board interconnects in space-constrained applications.
2 positions.
1.25mm.
1A.
150V.
Surface Mount, Right Angle.
-35°C to 85°C.
Gold with 8µin thickness.
