| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
52 pcs
|
52 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The ITT Cannon DEM5W1S is a D-Sub combo receptacle connector offering 5 positions arranged as 4 signal contacts plus 1 coax or power contact. It features a panel mount design with solder cup termination for secure wiring connections. The connector uses a 2-row layout with shell size 1 (DE, E) - 5W1.
This connector is fully shielded to reduce electromagnetic interference. The shell is constructed from steel with yellow chromate plated zinc finish providing durability and corrosion resistance. Contacts are gold flash plated for reliable signal transfer.
The mounting flange uses an unthreaded housing/shell design. The insulator material has a UL94 V-0 flammability rating. Contacts are not included with the connector, allowing selection of appropriate signal and coax or power contacts for specific applications.
The DEM5W1S is a panel mount connector with an unthreaded flange.
The current rating is 7.5 A per contact.
The connector uses signal and coax or power contacts, which are not included. The contact finish is gold flash.
Yes, it is a shielded connector.
