| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Package / Case | |
| Shell Material, Finish | |
| Shell Size | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The DDMF50P is a D-Sub connector assembly from Amphenol ICC. It is a plug with 50 male pins arranged in 3 rows. The connector features free hanging (in-line) mounting and solder cup termination for simple wire attachment.
Electrically, the DDMF50P is rated for 7.5A continuous current. The contacts are finished with gold for reliable signal integrity. The shell is made of steel with a yellow cadmium plating, providing durability and corrosion resistance. The connector uses shell size 5 (DD, D) and has a housing/shell (unthreaded) flange feature.
Compliance includes RoHS3 compliance, MSL 1 (unlimited), and REACH unaffected. The insulation material has a flammability rating of UL94 V-0. These specifications make the DDMF50P suitable for various interconnect applications requiring a robust, high-density D-Sub connection.
The DDMF50P has 50 positions.
The current rating is 7.5A.
The mounting type is free hanging (in-line).
The termination style is solder cup.
The contact finish is gold.
The shell size is 5 (DD, D).
The flammability rating is UL94 V-0.
