| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The ITT Cannon DDM24W7SF179A is a D-Sub Combo receptacle connector designed for applications requiring mixed signal and coax or power contacts. It features 24 positions arranged as 17 signal plus 7 coax or power positions in a 2-row layout. The connector uses a shell size 5 (DD, D) - 24W7 and is equipped with female sockets that have a gold flash contact finish.
Mounting is achieved via panel mount with through hole retention, and termination is wire wrap style. The shell is made of steel with yellow chromate plated zinc finish and includes a housing/shell unthreaded flange feature. The connector is shielded for EMI protection. The insulator material has a UL94 V-0 flammability rating.
This connector is suitable for industrial, telecommunications, and data communication equipment where a rugged, mixed-contact interface is required. Contacts are not included and must be ordered separately.
Receptacle, Female Sockets; D-Sub, Combo.
24 positions (17 signal + 7 coax or power).
Panel Mount, Through Hole; Wire Wrap termination.
7.5 A.
Yes, it is shielded.
Steel, Yellow Chromate Plated Zinc.
UL94 V-0.
