The Amphenol Advanced Sensors Type 95 series NTC thermistors, including the DC95G104V, are epoxy-coated, interchangeable thermistor chips designed for precise temperature measurement, control, and compensation. These sensors are suitable for applications operating between -80°C and 150°C (-112°F to 302°F), offering interchangeability down to ±0.1°C (±0.18°F).
Featuring high sensitivity, greater than -4%/°C at 25°C, and high reliability, these thermistors are constructed with a resin coating for good mechanical strength and resistance to solvents. They are available with various lead wire options, including bare tinned-copper, bare tinned-alloy, or PTFE-insulated lead wires. The DC95 series specifically utilizes bare tinned-copper lead wires.
Key specifications include a dissipation constant of 1 mW/°C in still air and 8 mW/°C in stirred oil, with a thermal time constant of 10 seconds in still air and 1 second in stirred oil. The maximum power dissipation at 25°C is 75 mW, de-rated from 100% at 25°C to 0% at 100°C. Options for other resistance values, tolerances, lead wire lengths, and custom configurations are available.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.04 | $2.04 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range is -80°C to 150°C.
The interchangeability is down to ±0.1°C.
The sensitivity is greater than -4%/°C at 77°F (25°C).
The dissipation constant in still air is 1 mW/°C.
The thermal time constant in stirred oil is 1 second.
The maximum power dissipation at 77°F (25°C) is 75 mW.
