| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | 714 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Flange Feature | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style | |
| Wire Gauge Range |
The ITT Cannon DBMA25PNM is a 25-position D-Sub plug connector from the D*MA series, designed for panel mount applications with crimp termination. It features male pins with gold contact finish for reliable signal transmission.
This connector is rated for 7.5A per contact and accepts wire gauges from AWG 18 to 28. The shell is made of brass with yellow chromate plated cadmium finish, and the insulator material has a UL94 V-0 flammability rating. It is designed for up to 500 mating cycles.
The DBMA25PNM is part of ITT Cannon's D*MA series, which is designed according to MIL-DTL-24308 standards, ensuring high reliability in demanding environments.
It is a D-Sub plug with male pins.
It has 25 positions arranged in 2 rows.
Panel mount with crimp termination.
7.5A per contact.
AWG 18 to 28.
UL94 V-0.
500 cycles.
