The DB102 is a single phase glass passivated bridge rectifier from SMC Diode Solutions. It is designed for converting AC to DC in power supply applications. Key electrical ratings include a maximum repetitive peak reverse voltage of 100V and an average rectified output current of 1A at TC=100°C.
The device features a low forward voltage drop of 1V at 1A and a high surge current capability of 45A (8.3ms single half sine-wave). The I²t rating is 8.404 A²s. Reverse leakage current is 5 µA at 25°C and 200 µA at 125°C. Junction capacitance is typically 25 pF.
The DB102 is housed in a DB-M molded plastic package with plated leads solderable per MIL-STD-202. It is through-hole mountable and can be mounted in any position. The package has a flammability rating of UL 94V-0. The device is Pb-free and RoHS compliant.
The DB102 has a maximum repetitive peak reverse voltage of 100V.
The DB102 can handle an average rectified output current of 1A at TC=100°C.
The maximum forward voltage drop is 1V at IF=1.0A and TJ=25°C.
The DB102 is available in a DB-M through-hole package (4-EDIP).
The non-repetitive peak forward surge current is 45A for an 8.3ms single half sine-wave.
The operating junction temperature range is -55°C to 150°C.
Typical thermal resistance is 40°C/W junction-to-ambient and 15°C/W junction-to-lead.
