DAL3W3P500G30LF DAL3W3P500G30LF is a D-Sub combo connector plug with 3 power positions rated at 30A. It features a right angle solder termination for through-hole mounting.
Mfr Part #:

DAL3W3P500G30LF

Available from 1 distributors
Mfr Name: Amphenol ICC
Amphenol ICC
DAL3W3P500G30LF is a D-Sub combo connector plug with 3 power positions rated at 30A. It features a right angle solder termination for through-hole mounting.
✓ Total Stock: 46 pcs

DAL3W3P500G30LF Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
46 pcs
On Request
46 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

DAL3W3P500G30LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Style
Connector Type
Contact Finish
Contact Type
Current Rating
Current Rating (Amps)
Features
Flange Feature
Material Flammability Rating
Mounting Type
Number of Positions
Number of Rows
Shell Finish
Shell Material
Shell Material, Finish
Shell Size
Shell Size, Connector Layout
Termination
Termination Style
View Similar Products (0)

DAL3W3P500G30LF Description

Short technical summary and product information.

The DAL3W3P500G30LF is a D-Sub combo connector from Amphenol ICC, designed for power applications requiring a compact and reliable interface. This plug connector features 3 power positions with male pins, each rated for 30A current, making it suitable for moderate power distribution within a D-Sub shell.



The connector uses a 3W3 shell size (DA, A) with a steel shell that has a nickel-plated finish for durability and EMI shielding. Contacts are gold-plated for reliable low-resistance connections. The through-hole, right-angle mounting style allows for efficient PCB layout, and the solder termination provides a secure permanent connection.



Additional design features include a board lock for secure attachment to the PCB, grounding indents for improved signal integrity, and mounting brackets for mechanical stability. The insulator is made from UL94 V-0 rated material for flammability compliance. This connector is RoHS3 compliant and REACH unaffected.

DAL3W3P500G30LF Quick Information

Product Type: D-Sub Connector Assembly
Canonical Name: D-Sub Combo Connector Plug, Male Pins, 3 (Power) Positions, Through Hole Right Angle Solder
Subcategory: Power Contacts

DAL3W3P500G30LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

DAL3W3P500G30LF Features

  • 3 power positions rated for 30A each.
  • Right-angle solder termination for through-hole.
  • Steel shell with nickel-plated finish.
  • Gold-plated power contacts.
  • UL94 V-0 rated insulator material.

DAL3W3P500G30LF Applications

  • Power distribution in D-Sub connector systems.
  • Industrial control and automation equipment.
  • Test and measurement instrumentation.
  • Telecommunications and networking hardware.

DAL3W3P500G30LF FAQs

6 frequently asked questions generated from this part’s specifications.
How many positions does the DAL3W3P500G30LF have?

It has 3 power positions.

What is the current rating of this connector?

The current rating is 30A per contact.

What is the mounting type for this connector?

It is through-hole, right-angle mounting with solder termination.

What shell size and layout does this connector use?

It uses shell size 2 (DA, A) with a 3W3 layout.

What is the contact finish on this connector?

The contact finish is gold.

What is the flammability rating of the insulator?

The material flammability rating is UL94 V-0.
