| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,600 pcs
|
3600 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
14 pcs
|
14 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Architecture | |
| Automotive Grade | |
| Data Interface | |
| Differential Output | |
| INL | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Bits | |
| Number of D | |
| Operating Temperature | |
| Operating Voltage | |
| Output Type | |
| Power Consumption | |
| Reference Type | |
| Resolution | |
| Settling Time | |
| Supplier Device Package | |
| Tape & Reel | |
| Voltage |
The DAC7512N/250 from Texas Instruments is a single-channel, 12-bit digital-to-analog converter (DAC) designed for low-power applications. It provides a buffered voltage output with a rail-to-rail swing capability, allowing for efficient use of the output voltage range from 0 to 5.5V.
This DAC utilizes a three-wire serial interface compatible with SPI, QSPI, Microwire, and DSP protocols, operating at clock rates up to 30MHz. Key electrical specifications include a 12-bit resolution, a settling time of 10µs, and an integral non-linearity (INL) of ±8 LSB maximum. The device operates from a power supply voltage of 2.7V to 5.5V, with typical power consumption of 0.345mW.
The DAC7512N/250 is available in a compact SOT-23-6 surface-mount package, making it suitable for space-constrained designs. Its operating temperature range is -40°C to 105°C. Applications include portable battery-powered instruments, digital gain and offset adjustment, and programmable voltage sources.
This DAC is designed with features such as power-on reset to 0V and three power-down functions, contributing to its low-power operation. The on-chip output buffer amplifier ensures rail-to-rail operation, simplifying external circuitry.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.76 | $2.76 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The DAC7512N/250 has a resolution of 12 bits.
The output voltage range is 0 V to 5.5 V.
It uses an SPI and DSP serial interface.
The operating temperature range is -40°C to 105°C.
The package type is SOT-23-6.
The typical power consumption is 0.345 mW.
The settling time is 10 µs.
