| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,708 pcs
|
4708 pcs | On Request | 1 | On Request | On Request | 11+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Contact Plating | |
| Interface | |
| Number of Channels | |
| Number of Outputs | |
| Output Type | |
| Package / Case | |
| Package Quantity | |
| Power Consumption | |
| Power Dissipation | |
| Resolution | |
| Settling Time | |
| Supply Current | |
| Supply Voltage | |
| Weight |
The Texas Instruments DAC712U is a 16-bit digital-to-analog converter (DAC) designed for high-speed applications with a conversion rate of 100 kS/s. It features a 16-bit parallel bus interface, allowing for efficient data transfer.
Key electrical characteristics include integral and differential nonlinearity of 4 LSB, ensuring good accuracy. The DAC712U provides a bipolar voltage output and operates with a dual supply voltage range from 11.4V to 16.5V. It has a typical supply current of 22mA and a maximum power dissipation of 600mW.
This component is housed in a 28-pin SOIC package with gold contact plating, suitable for surface mounting. It is designed for operation in temperatures ranging from -40°C to 85°C. The DAC712U is RoHS compliant, indicating adherence to environmental standards.
With its combination of speed, accuracy, and package type, the DAC712U is suitable for various data conversion applications requiring precise analog output from digital signals.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.25 | $2.25 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The DAC712U has a resolution of 16 bits.
The DAC712U has a conversion rate of 100 kS/s.
The integral and differential nonlinearity for the DAC712U are both 4 LSB.
The DAC712U provides a bipolar voltage output.
The DAC712U operates with a dual supply voltage range of 11.4V to 16.5V.
The DAC712U is suitable for operation between -40°C and 85°C.
The DAC712U is supplied in a 28-pin SOIC package.
