| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
49 pcs
|
49 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Current Rating (Amps) | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The DA7W2SA00LF is a D-Sub Combo connector from Amphenol ICC. It is a receptacle with female sockets, featuring 7 positions arranged as 5 signal and 2 power contacts. The connector uses a 2 (DA, A) - 7W2 shell size and layout.
Termination is via solder cup, suitable for free hanging (in-line) mounting. The shell is steel with nickel plating, and the contacts are finished with gold-palladium. The housing material has a UL94 V-0 flammability rating.
This connector is designed for applications requiring mixed signal and power connections in a compact D-Sub form factor. The current rating is 7.5 A per contact.
7 positions (5 signal + 2 power).
7.5 A per contact.
Free hanging (in-line).
2 (DA, A) - 7W2.
Gold-palladium.
Solder cup.
Yes, RoHS3 compliant.
