D38999/26FF32PN The Amphenol Socapex D38999/26FF32PN is a high-reliability, high-durability circular connector designed for demanding military, aerospace, and marine applications. It features 32 positions and a Pin contact type.
Mfr Part #:

D38999/26FF32PN

Available from 1 distributors
Mfr Name: Amphenol Socapex
Amphenol Socapex
The Amphenol Socapex D38999/26FF32PN is a high-reliability, high-durability circular connector designed for demanding military, aerospace, and marine applications. It features 32 positions and a Pin contact type.
✓ Total Stock: 1 pcs
$ Price Range: $1.00

D38999/26FF32PN Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

D38999/26FF32PN Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Contact Type
Finish
Locking Feature
Material
Mounting Type
Storage Temperature
Tape & Reel
Temperature Rating
View Similar Products (0)

D38999/26FF32PN Description

Short technical summary and product information.

The Amphenol Socapex D38999/26FF32PN is a MIL-DTL-38999 Series III qualified circular connector. It is engineered for high reliability and durability in harsh environments, making it suitable for military, aerospace, aviation, and marine applications.



This connector features a straight plug shell type with an aluminum material and electroless nickel finish, providing 48-hour salt spray resistance. It operates within a temperature range of 200°C and offers superior EMI shielding capability of 65dB minimum at 10 GHz. The insert arrangement includes 32 #20 contacts, all of the pin type.



Key design features include a scoop-proof contact protection system, a quick coupling mechanism with a self-locking feature that eliminates the need for lockwiring, and improved moisture resistance. These attributes ensure high performance under severe vibration and high impact shock conditions.



Applications for the D38999/26FF32PN include rockets, space vehicles, military and commercial aircraft, avionics, unmanned systems, communications equipment, armored personnel carriers, tanks, high-temperature industrial equipment, missile defense systems, and ships.

D38999/26FF32PN Quick Information

Product Type: Circular Connector
Series: Series III
Canonical Name: Amphenol Socapex D38999/26FF32PN Circular Connector
Subcategory: D-Sub, D-Shaped Connector Accessories

D38999/26FF32PN Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

D38999/26FF32PN Estimated Pricing

Qty Low High
1+ $1.00 $1.00

Estimated market price range - modelled values for guidance only, not live distributor offers.

D38999/26FF32PN Features

  • High reliability, high durability circular connector.
  • MIL-DTL-38999 Series III qualified.
  • 32 positions with Pin contact type.
  • Electroless Nickel finish for 48-hour salt spray.
  • Operates up to 200°C with EMI shielding.

D38999/26FF32PN Applications

  • Used in military aircraft and spacecraft.
  • Suitable for avionics and unmanned systems.
  • Applied in communications equipment.
  • Found in armored vehicles and ships.
  • Designed for high temperature industrial use.

D38999/26FF32PN FAQs

7 frequently asked questions generated from this part’s specifications.
What is the shell type for the D38999/26FF32PN connector?

The shell type is 26.

What material and finish does the D38999/26FF32PN connector have?

The connector is made of Aluminum with an Electroless Nickel finish.

What is the operating temperature range for this connector?

It operates up to 200°C.

How effective is the EMI shielding on the D38999/26FF32PN?

It provides a minimum EMI shielding of 65dB at 10 GHz.

What is the salt spray resistance rating?

It has a 48-hour salt spray resistance.

How many positions and what contact type does this connector feature?

It has 32 positions and uses Pin contact types.

Does this connector have a self-locking mechanism?

Yes, it features a unique, self-locking, quick coupling connector.
