| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
40 pcs
|
40 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Contact Material | |
| Contact Plating | |
| Contact Type | |
| Durability | |
| Gender | |
| Insulator Material | |
| Orientation | |
| Plating | |
| Shell Material | |
| Storage Temperature | |
| Tape & Reel |
The Amphenol Socapex D38999/24WC04PN is a D38999 Series III Mil Spec Connector designed for demanding applications. It features 4 pin crimp contacts with a copper alloy construction and gold plating, housed in a durable shell available in aluminum alloy, stainless steel, or titanium alloy with various plating options including Olive Drab Cadmium over Electroless Nickel.
This connector complies with the MIL-DTL-38999M standard and offers robust performance characteristics. It provides electromagnetic shielding and is designed for high-intensity vibration at high temperatures, making it suitable for harsh environments. The connector supports various contact types including crimp, welding, and PCB, with options for 16# contact holes to assemble fiber contacts and 12#, 10#, 8# contact holes for coaxial or shield contacts.
Key performance specifications include a durability of over 500 cycles, sinusoidal vibration resistance of 60g, and random vibration resistance of 41.7g under high temperature conditions. The insulator is made from thermoset or thermoplastic material, and it utilizes silicone rubber for grommets and seals. The standard transport package is PP+Carton.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.00 | $3.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The contact material is copper alloy with gold plating.
It uses crimp pin contacts, with options for welding and PCB types.
The durability is rated for a minimum of 500 cycles.
It has a sinusoidal vibration rating of 60g and a random vibration rating of 41.7g under high temperature.
It complies with the MIL-DTL-38999M standard.
The Moisture Sensitivity Level is 1 Unlimited.
