| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
79 pcs
|
79 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The 3M D2510-6V0C-AR-WD is a 10 position, 2-row shrouded header designed for board-to-cable/wire applications. It features male square pins with a 2.54mm pitch and 0.100" row spacing, making it compatible with standard ribbon cable connectors. The header is surface mount with solder termination and a push-pull fastening type.
The connector is rated for 1.75A per contact and operates over a temperature range of -55°C to 105°C. The insulation is black glass-filled PCT/polyester with a UL94 V-0 flammability rating. Contacts are brass with a 10.0µin tin finish. The shrouded 4-wall design provides pin protection and keying slot for polarization. A pick-and-place feature aids automated assembly.
The pitch is 2.54mm (0.100").
It has 10 positions in 2 rows, all positions loaded.
The current rating is 1.75A per contact.
It is surface mount with solder termination.
The operating temperature range is -55°C to 105°C.
