| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
240 pcs
|
240 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Backset Spacing | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination |
The Amphenol ICC D09P13F6GL00LF is a 9-position D-Sub plug connector featuring male pins arranged in 2 rows. It is designed for through hole mounting with a right angle orientation, making it suitable for applications where space constraints require a low-profile connection. The connector uses solder termination for reliable electrical connections.
This connector has a shell size of 1 (DE, E) and a steel, tin-plated shell for durability and EMI shielding. The contacts are signal type with a gold or Gold, GXT™ finish of 30.0 µin (0.76 µm) for corrosion resistance and reliable mating cycles. The flange feature includes housing/shell (M3) mounting holes, and the backset spacing is 0.409" (10.40 mm).
Additional features include board locks, grounding indents, and mounting brackets to secure the connector to the PCB. The current rating is 5 A, and the insulator material has a UL94 V-0 flammability rating. This connector is RoHS3 compliant and REACH unaffected.
The connector has 9 positions arranged in 2 rows.
Through hole, right angle mounting with solder termination.
The current rating is 5 A.
Gold or Gold, GXT™ finish with 30.0 µin (0.76 µm) thickness.
Yes, it is RoHS3 compliant.
