| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
950 pcs
|
950 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
580 pcs
|
580 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accessory Type | |
| For Use With | |
| Mounting Type | |
| Number of Anchors Required |
The D057 is a solder anchor manufactured by Aavid, Thermal Division of Boyd Corporation, designed specifically for use with BGA heat sinks. This accessory provides a secure mechanical attachment point for heat sink clips by being soldered directly to the printed circuit board.
According to the manufacturer's datasheet, 2 to 4 solder anchors must be soldered to the PCB prior to attaching the heat sink clip. The anchors are sold separately, allowing designers to order the exact quantity needed for their application.
The solder anchor uses a solder mounting method, which provides a reliable and permanent connection to the PCB. This mounting approach is well-suited for BGA heat sink applications where mechanical stability and thermal performance are critical.
This product falls under the Thermal Accessories category within the Thermal Management product family, making it a suitable choice for engineers designing thermal solutions for BGA packages.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.31 | $0.31 |
| 10+ | $0.29 | $0.29 |
| 100+ | $0.28 | $0.28 |
| 250+ | $0.26 | $0.26 |
| 500+ | $0.26 | $0.26 |
| 1,000+ | $0.24 | $0.24 |
| 2,500+ | $0.22 | $0.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The D057 is a solder anchor designed for use with BGA heat sinks.
According to the datasheet, 2 to 4 solder anchors must be soldered to the PCB prior to attaching the heat sink clip.
The D057 uses solder mounting, providing a permanent connection to the PCB.
Yes, the solder anchors are sold separately from the heat sink clips.
