| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10 pcs
|
10 pcs | On Request | 10 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| Termination | |
| Termination Style |
The D01-9942001 is a single row (1x20) SIL header from Harwin Inc. It features 20 positions with a 2.54mm (0.100") pitch, making it suitable for standard breadboard and prototyping applications. The connector uses slotted contacts with a tin finish (3.50µm thickness) and through hole solder termination. The housing is black and the component is RoHS3 compliant. This header is designed for use in rectangular interconnect systems, commonly found in industrial, automotive, and consumer electronics. The through hole mounting ensures reliable mechanical connection to the PCB. Contact material is not specified, but the tin finish provides good solderability and corrosion resistance.
20 positions in a single row.
2.54mm (0.100")
Through hole, with solder termination.
Tin, with a thickness of 3.50µm (137.8µin).
Single row (1 row).
Black.
Yes, RoHS3 compliant.
