| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
78,400 pcs
|
78400 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Voltage |
The Infineon PSoC 4000S MCU, part number CY8C4025LQI-S411, is built around an Arm Cortex-M0+ CPU running at up to 48MHz. This microcontroller features 32KB of flash memory with read accelerators and 4KB of SRAM.
It includes programmable analog and digital blocks, a 10-bit ADC, two current DACs, and two low-power comparators. The device supports capacitive sensing with high signal-to-noise ratio and automatic hardware tuning (SmartSense). It also offers LCD segment drive capability.
Connectivity options include two reconfigurable serial communication blocks (SCB) supporting I2C, SPI, or UART protocols. For timing and pulse width modulation, there are five 16-bit timer/counter/PWM blocks. The microcontroller supports up to 36 programmable GPIO pins.
Operating within a voltage range of 1.71V to 5.5V, the CY8C4025LQI-S411 features a deep sleep mode with low system current. It is available in various packages including TQFP, QFN, and WLCSP, supporting surface mount installation.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.99 | $2.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The core is an Arm Cortex-M0+ CPU.
The CPU operates at a maximum frequency of 48MHz.
It has up to 32KB of flash memory.
The SRAM capacity is up to 4KB.
The operating voltage range is from 1.71V to 5.5V.
It supports I2C, SPI, or UART interfaces.
There are up to 36 programmable GPIO pins.
