| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Input Voltage | |
| Length | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The TDK Corporation CUS250M-12 is a versatile 250W AC-DC power supply designed for ITE (Commercial), Laboratory, and Medical applications. This open frame converter operates with a 12V output voltage and offers a high efficiency of 94%.
Packaged in a compact 2 x 4 inch footprint, the CUS250M-12 is suitable for chassis mounting. It supports a wide input voltage range of 80-264 VAC and operates efficiently across various ambient temperatures. The series is known for its Class B conducted and radiated EMI performance and certifications for Class I and Class II installations.
Key features include adjustable output, power factor correction (PFC), and a standby output. The unit is compliant with safety standards such as IEC/EN/UL 61010-1, 60601-1, 60950-1, and 62368-1, making it suitable for demanding applications.
80-264 VAC.
Open frame, chassis mount.
-20°C to 85°C with derating.
12V.
20.83 A.
94%.
61010-1, 60601-1, 60950-1, 62368-1.
