CTES035V0-G TVS diode array with 300W peak pulse power, 5V reverse standoff voltage, and 10V clamping voltage. Features 2 unidirectional channels in a SOT-23-3 surface mount package.
Mfr Part #:

CTES035V0-G

Available from 1 distributors
Mfr Name: Comchip Technology
Comchip Technology
TVS diode array with 300W peak pulse power, 5V reverse standoff voltage, and 10V clamping voltage. Features 2 unidirectional channels in a SOT-23-3 surface mount package.
✓ Total Stock: 2,795 pcs
$ Price Range: $0.12 - $0.30

CTES035V0-G Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
2,795 pcs
On Request
2795 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CTES035V0-G Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Current
Mounting Type
Operating Temperature
Package / Case
Power
Power Line Protection
Supplier Device Package
Tape & Reel
Termination Style
Type
Unidirectional Channels
Voltage
View Similar Products (0)

CTES035V0-G Description

Short technical summary and product information.

The CTES035V0-G is a 300W transient voltage suppressor (TVS) diode array from Comchip Technology. It provides ESD protection with a rating of 16kV per IEC 61000-4-2 and transient protection for 8/20µs waveforms. The device features two unidirectional channels with a reverse standoff voltage of 5V and a maximum clamping voltage of 10V at 1A. Peak pulse current is rated at 17A (8/20µs).



This TVS array is designed for general purpose applications such as transient/ESD suppression in LAN/WAN, peripherals, and set-top boxes. It operates over a temperature range of -55°C to 125°C. The SOT-23-3 package is surface mountable with gull wing leads, suitable for automated assembly.



Electrical characteristics include a minimum reverse breakdown voltage of 6.0V at 1mA, maximum reverse leakage current of 10µA at 5V, and typical capacitance of 350pF at 1MHz. The device is RoHS compliant.

CTES035V0-G Quick Information

Product Type: TVS Diode Array
Series: CT
Canonical Name: Comchip Technology CTES035V0-G TVS Diode Array, 300W, 5V Standoff, SOT-23-3
Subcategory: TVS Diode Array

CTES035V0-G Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 (Unlimited)
REACH Status: REACH Unaffected

CTES035V0-G Estimated Pricing

Qty Low High
1+ $0.30 $0.30
10+ $0.26 $0.26
25+ $0.23 $0.23
100+ $0.20 $0.20
250+ $0.17 $0.17
500+ $0.15 $0.15
1,000+ $0.12 $0.12

Estimated market price range - modelled values for guidance only, not live distributor offers.

CTES035V0-G Features

  • 300W peak pulse power (8/20µs).
  • Two unidirectional ESD protection channels.
  • 5V reverse standoff voltage.
  • 16kV ESD rating per IEC 61000-4-2.
  • Surface mount SOT-23-3 package.

CTES035V0-G Applications

  • Protects data lines in LAN/WAN equipment.
  • Used in peripheral interfaces.
  • Suitable for set-top box transient suppression.
  • General purpose ESD protection for portable devices.

CTES035V0-G FAQs

7 frequently asked questions generated from this part’s specifications.
What is the reverse standoff voltage (VRWM) of the CTES035V0-G?

5V.

What is the minimum reverse breakdown voltage?

6.0V at 1mA.

What is the maximum clamping voltage?

10V at 1A (8/20µs).

What is the peak pulse current rating?

17A (8/20µs).

What package does the CTES035V0-G come in?

SOT-23-3 surface mount package.

What is the ESD rating of this TVS diode?

16kV per IEC 61000-4-2.

What is the typical capacitance of the CTES035V0-G?

350pF at 1MHz.
