CT2016DB19200C0FLHA1 Surface mount crystal with integrated thermistor. 19.2 MHz frequency, 7pF load capacitance, ±10ppm tolerance, in a 2.00mm x 1.60mm package.
Mfr Part #:

CT2016DB19200C0FLHA1

Available from 3 distributors
Mfr Name: Kyocera AVX
Kyocera AVX
Surface mount crystal with integrated thermistor. 19.2 MHz frequency, 7pF load capacitance, ±10ppm tolerance, in a 2.00mm x 1.60mm package.
✓ Total Stock: 3,719 pcs
$ Price Range: $0.58 - $1.03

CT2016DB19200C0FLHA1 Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
2,278 pcs
On Request
2278 pcs On Request 1 On Request On Request 18/19 On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
788 pcs
On Request
788 pcs On Request 1 On Request On Request 1508+ On Request On Request
Rayichip ✓
Non-Authorised Inventory information
653 pcs
On Request
653 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CT2016DB19200C0FLHA1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
ESR (Equivalent Series Resistance)
Frequency
Frequency Stability
Frequency Tolerance
Height
Insulation Resistance
Lead Style
Length
Load Capacitance
Mounting Type
Operating Mode
Operating Temperature
Storage Temperature
Tape & Reel
Type
Width
View Similar Products (0)

CT2016DB19200C0FLHA1 Description

Short technical summary and product information.

The CT2016DB19200C0FLHA1 is a 19.2 MHz crystal unit from Kyocera AVX, part of the CT2016DB series designed for surface mount applications. It integrates a thermistor for temperature sensing, making it suitable for compensated crystal oscillator designs.



Electrical characteristics include a nominal frequency of 19.2 MHz, load capacitance of 7.0 pF, frequency tolerance of ±10 ppm at +25°C, and frequency stability of ±12 ppm over -30°C to +85°C. Maximum equivalent series resistance is 80 Ω. The integrated thermistor has a resistance of 100 kΩ at 25°C with a B-constant of 4250 K.



The crystal is housed in a compact 4-SMD, No Lead package measuring 2.00 mm x 1.60 mm x 1.00 mm. It is rated for surface mount assembly and is RoHS compliant with MSL 1 moisture sensitivity level.

CT2016DB19200C0FLHA1 Quick Information

Product Type: Crystal
Series: CT2016DB
Canonical Name: CT2016DB Series Crystal with Thermistor, 19.2 MHz, 7pF, Surface Mount
Subcategory: Crystal with Thermistor

CT2016DB19200C0FLHA1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): MSL 1
REACH Status: REACH Unaffected
Lead Free: Yes

CT2016DB19200C0FLHA1 Estimated Pricing

Qty Low High
1+ $1.03 $1.03
10+ $0.88 $0.88
25+ $0.84 $0.84
100+ $0.76 $0.76
250+ $0.68 $0.68
500+ $0.66 $0.66
1,000+ $0.66 $0.66
3,000+ $0.61 $0.61
6,000+ $0.58 $0.58

Estimated market price range - modelled values for guidance only, not live distributor offers.

CT2016DB19200C0FLHA1 Features

  • 19.2 MHz fundamental mode crystal.
  • Integrated thermistor for temperature compensation.
  • ±10ppm frequency tolerance at 25°C.
  • Compact 2.00mm x 1.60mm SMD package.
  • RoHS compliant and MSL 1 rated.

CT2016DB19200C0FLHA1 Applications

  • Ideal for GPS timing circuits.
  • Used in wireless communication modules.
  • Frequency reference for IoT devices.
  • Suitable for portable electronics.

CT2016DB19200C0FLHA1 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the package type of this crystal?

4-SMD, No Lead surface mount package.

What is the operating temperature range?

-30°C to +85°C.

Is this crystal RoHS compliant?

Yes, RoHS3 compliant per datasheet.

What is the frequency tolerance?

-10.0/+10.0 ppm at +25±3°C.

What load capacitance is required?

7.0 pF.

What is the equivalent series resistance?

Maximum 80 Ω.

Does this crystal include a thermistor?

Yes, integrated thermistor with 100 kΩ resistance at 25°C.
