The Celem CSM 300N is a high-power, conduction-cooled capacitor designed for demanding applications. It utilizes advanced Celem soldering technology for enhanced safety margins and longevity.
Key electrical specifications include a maximum power rating of 300 kVAr and a wide range of capacitance values from 0.1 μF to 5 μF. The capacitor operates with sinusoidal voltages up to 1000 Vrms and peak voltages up to 1410 Vpeak, with maximum current ratings up to 800 Arms depending on the capacitance value. It features low ESR and low losses, contributing to efficient operation.
Constructed with polypropylene, the CSM 300N is a self-healing capacitor, providing reliability in operation. It is available with UL94-V0 compliance upon request. The capacitor's dimensions are 68 x 60 x 30.2 mm, with a weight of 0.55 kg.
Standard applications for the CSM 300N include medical equipment, EV charging, Induction Power Transfer (IPT), high-frequency inverters, Induction Heating, Heat Treatment, and Wireless Power Transfer systems. The CSM 300N complies with RoHS.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The CSM 300N capacitor is available with capacitance values of 0.1 μF, 0.2 μF, 0.33 μF, 0.66 μF, 1 μF, 1.32 μF, 2.6 μF, and 5 μF, with a tolerance of ±10%.
The maximum sinusoidal voltage rating varies with capacitance, ranging from 1000 Vrms for 0.1 μF down to 500 Vrms for 5 μF.
The maximum current rating varies with capacitance, ranging from 400 Arms for 0.1 μF up to 800 Arms for 5 μF.
The dimensions of the CSM 300N capacitor are 68 mm in length, 60 mm in width, and 30.2 mm in height.
The CSM 300N capacitor is constructed with polypropylene.
Yes, the CSM 300N capacitor complies with RoHS.
