| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,300 pcs
|
3300 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Failure Rate | |
| Height | |
| Length | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Resistance | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Temperature Coefficient | |
| Termination Style | |
| Tolerance | |
| Voltage | |
| Width |
This TE Connectivity CRG0805F270R is a high-quality thick film surface mount resistor. It offers a resistance value of 270 Ohms with a tight tolerance of ±1%, making it suitable for precise applications. The resistor has a power rating of 0.125W (1/8W) and operates within a temperature range of -55°C to 155°C.
The component is housed in an industry-standard 0805 package, measuring 2.00mm in length and 1.25mm in width. Its thick film technology provides a robust and reliable solution for various electronic designs. The general-purpose nature of this resistor makes it versatile for use in a wide array of industrial and commercial applications.
Key electrical characteristics include a voltage rating of 150V and a temperature coefficient of ±100 ppm/°C. The termination style is solder, and it is supplied in tape and reel packaging, suitable for automated assembly processes. This resistor is designed for high-frequency operation due to its short lead structure and low capacitance.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 270 Ohms.
The tolerance is ±1%.
The power rating is 0.125W or 1/8W.
The operating temperature range is -55°C to 155°C.
The 0805 package measures 2.00mm in length and 1.25mm in width.
The temperature coefficient is ±100 ppm/°C.
The voltage rating is 150V.
