The Panasonic CR-1220/FCN is a non-rechargeable lithium manganese dioxide coin cell battery. It provides a nominal voltage of 3V and a nominal capacity of 35mAh, delivering reliable power for compact applications.
Key specifications: the battery measures 12.5mm in diameter and 2.0mm in height, weighing 1.2g. It operates over a temperature range of -30°C to +60°C. Termination is via PC pins for vertical PCB mounting, enabling direct integration into circuit boards.
The lithium manganese dioxide chemistry offers good pulse capability, high discharge characteristics, and stable voltage during discharge, contributing to long-term reliability. The battery is claimed to be RoHS3 compliant and REACH unaffected, though these statuses are unverified.
Packaging is a standard coin cell (12.5mm). The battery is intended for primary (non-rechargeable) use in devices requiring a compact, low-profile power source.
3V.
Coin, 12.5mm diameter.
-30°C to +60°C.
RoHS3 compliant (unverified).
35mAh.
Lithium Manganese Dioxide.
PC Pin (Vertical Mount).
