The Bel Power Solutions CPA550-4530G is a 550W AC-DC converter designed for Compact PCI systems, suitable for ITE (Commercial) applications. It features a wide input voltage range of 90-264VAC with PFC and provides four outputs: 5V, 3.3V, 12V, and -12V, with corresponding currents of 50A, 60A, 12A, and 4A. The converter operates with convection cooling and has an efficiency of 84%.
Key features include DC input capability, hot-swappable operation, load sharing, and remote sense lines. It is protected against overtemperature, overvoltage, overcurrent, and overpower conditions. The unit is safety-approved to UL/CSA 60950-1 and IEC/EN 62368-1 standards. Its dimensions are 172 x 40.6 x 261.9 mm, and it utilizes a 47-pin Positronic connector for mounting.
This converter is compliant with PICMG® CompactPCI® specifications, making it ideal for integration into CompactPCI® architectures. It offers high power density and reliability for demanding applications.
The CPA550-4530G has a power output of 550W.
The input voltage range for the CPA550-4530G is 90-264VAC.
The CPA550-4530G has 4 outputs.
The output voltages for the CPA550-4530G are 5V, 3.3V, 12V, and -12V.
The operating temperature range of the CPA550-4530G is -25°C to 50°C.
The CPA550-4530G uses convection cooling.
The CPA550-4530G is safety-approved to UL/CSA 60950-1 and IEC/EN 62368-1.
