| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
700 pcs
|
700 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Color Temperature | |
| Configuration | |
| Current | |
| Forward Current | |
| Forward Voltage | |
| Height | |
| Height (Max) | |
| Lens Diameter | |
| Lens Size | |
| Lens Style | |
| Lens Transparency | |
| Maximum Operating Temperature | |
| Millicandela Rating | |
| Minimum Operating Temperature | |
| Mounting Type | |
| Packaging Method | |
| Power Dissipation | |
| Reverse Voltage | |
| Supplier Device Package | |
| Viewing Angle | |
| Voltage | |
| Wavelength |
The Cree CP41B-WES-CM0P0244 is a standard discrete LED designed for through-hole mounting. It emits a cool white light with a typical luminous intensity of 5200 mcd and a color temperature of 9000 K. This LED operates with a typical forward current of 30mA and a forward voltage of 3.6V, and has a maximum reverse voltage of 5V.
The component features a clear, domed lens with a diameter of 3mm, and the overall LED dimensions are 7.6mm in length and width, with a maximum height of 6.55mm. The viewing angle is 60 degrees. It is rated for a power dissipation of 154mW and can operate within a temperature range of -40°C to +95°C.
Packaged in a tube, this LED is suitable for various general indication applications where a reliable through-hole component is required. Its specifications make it a versatile choice for circuit board indicators and other electronic assemblies.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.08 | $0.08 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical forward voltage for the CP41B-WES-CM0P0244 LED is 3.6V.
The typical luminous intensity of the CP41B-WES-CM0P0244 LED is 5200 mcd.
The typical viewing angle for the CP41B-WES-CM0P0244 LED is 60 degrees.
The CP41B-WES-CM0P0244 LED can operate between -40°C and +95°C.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
