| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,640 pcs
|
2640 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Lead Style | |
| Mounting Type | |
| Reverse Recovery Time (trr) | |
| Tape & Reel |
The Central Semiconductor CMPD2838E TR is a general-purpose diode array designed for surface mount applications. It features a maximum DC reverse voltage of 120V and an average rectified current of 200mA per diode. The forward voltage is a maximum of 1V at 100mA, with a typical reverse leakage current of 100nA at 80V. The component has a fast reverse recovery time of 4ns.
This diode array is packaged in a TO-236-3, SC-59, SOT-23-3 configuration, suitable for surface mounting. The operating junction temperature ranges from -65°C to 150°C. It is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1.
This part is suitable for general-purpose rectification and switching applications where space is a constraint and surface mounting is required. Its specifications make it a reliable choice for various electronic circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum DC reverse voltage is 120V.
The typical average rectified current is 200mA per diode.
The typical reverse recovery time is 4ns.
The operating junction temperature range is -65°C to 150°C.
It is available in a surface-mount TO-236-3, SC-59, or SOT-23-3 package.
The maximum forward voltage is 1V at 100mA.
The typical reverse leakage current is 100nA at 80V.
