| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| Current Rating (Max) | |
| DC Resistance (DCR) | |
| DC Resistance (DCR) (Max) | |
| Height (Max) | |
| Inductance @ Frequency | |
| Mounting Type | |
| Number of Lines | |
| Operating Temperature |
The CM1011-175 is a common mode choke manufactured by API Delevan Inc. It features a nominal inductance of 1.7 mH measured at 1 kHz, a maximum current rating of 3.1A, and a maximum DC resistance of 60 mOhm. The component contains 2 lines for filtering common mode noise in power and signal lines.
The choke is designed for through-hole mounting with a horizontal, 4 PC pin package. Its dimensions are 27.90mm x 27.90mm with a maximum height of 18.56mm. The operating temperature range spans from -55°C to 125°C, making it suitable for demanding environments.
This component is intended for use in filtering applications where common mode noise suppression is required. The through-hole package provides reliable mechanical mounting and is suitable for manual or wave soldering processes.
| Qty | Low | High |
|---|---|---|
| 50+ | $29.81 | $29.81 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 1.7 mH measured at 1 kHz.
The maximum current rating is 3.1A.
The maximum DC resistance is 60 mOhm.
It has 2 lines.
The operating temperature range is -55°C to 125°C.
It is through-hole mounted with a horizontal, 4 PC pin package.
The dimensions are 27.90mm x 27.90mm with a maximum height of 18.56mm.
