| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,250 pcs
|
1250 pcs | On Request | 1 | On Request | On Request | 720 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Flammability Rating | |
| Insertion Depth (Bottom Entry) | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Packaging Type | |
| Pitch | |
| Row Spacing | |
| SMT Lead Coplanarity | |
| Style | |
| Termination | |
| Termination Style |
The Samtec CLT-107-02-LM-D-BE-TR is a 14-position, 2.00mm pitch, dual-row receptacle designed for board-to-board applications. It features a bottom entry configuration with surface mount (SMT) solder termination, making it suitable for compact stacking designs. The connector uses female socket contacts made of phosphor bronze with a gold flash on the contact area (10µin) and matte tin on the tail, as indicated by the LM plating option. Each contact is rated for 4.1A, and the insulator is made of black liquid crystal polymer with a UL94 V-0 flammability rating. The operating temperature range is -55°C to 125°C. The connector is packaged in tape and reel (TR suffix) for automated assembly. SMT lead coplanarity is maintained at a maximum of 0.10mm for this position count. The push-pull fastening type ensures secure mating with compatible headers such as TMM, TMMH, MTMM, MMT, TW, and TSH series.
14 positions, all loaded in 2 rows.
2.00mm (0.079 in) pitch.
4.1 A per contact.
Surface mount with solder termination.
-55°C to 125°C.
Contacts are phosphor bronze with gold plating (10µin) on contact area. Insulator is black liquid crystal polymer with UL94 V-0 rating.
RoHS3 compliant per existing database records (unverified).
