| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Ratings | |
| Termination Style | |
| Topology | |
| Type | |
| Voltage | |
| Width |
The Mean Well USA CLG-100-48 is a single-output LED driver designed for constant current and constant voltage operation. It accepts a nominal 90VAC input and delivers an output of 36-48V at 2A, providing 96W of power with an efficiency of 88.5%.
This AC-DC converter features built-in protections including overcurrent (OCP), overtemperature (OTP), overvoltage (OVP), and short circuit (SCP). The driver is housed in a compact metal enclosure measuring 198.2mm x 68.0mm x 38.8mm with wire lead terminations, suitable for indoor or outdoor use with an IP67 rating.
Operating temperature range is -30°C to 70°C, and the unit carries multiple safety approvals including CB, CCC, CE, PSE, TUV, and UR. It is RoHS3 compliant and REACH unaffected.
The nominal input voltage is 90VAC.
The operating temperature range is -30°C to 70°C.
Yes, it is RoHS3 compliant.
Output current is 2A and output power is 96W.
Overcurrent (OCP), overtemperature (OTP), overvoltage (OVP), and short circuit (SCP) protections.
The driver is rated IP67.
Approvals include CB, CCC, CE, PSE, TUV, and UR.
