| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
386 pcs
|
386 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Shielding | |
| Storage Temperature | |
| Tape & Reel | |
| Tolerance | |
| Type | |
| Width |
This TDK Corporation CLF10040T-150M is a fixed inductor from the CLF Series, designed for power circuits. It features a wirewound drum core construction and is shielded to minimize magnetic interference.
The inductor provides an inductance value of 15µH with a tolerance of ±20%. It has a maximum DC resistance of 48mOhm and can handle a continuous current rating of 2.5A, with a saturation current of 3.2A. The operating temperature range is from -40°C to 105°C.
Designed for surface mounting, this component has dimensions of 10.00mm in length, 9.70mm in width, and 4.10mm in height. The ferrite material contributes to its magnetic properties. This inductor is suitable for general electronic equipment applications where reliable power inductance is required.
Compliance information indicates RoHS3 compliance, MSL 1 Unlimited, and REACH unaffected status, though these are currently unverified.
The inductance value is 15µH.
The continuous current rating is 2.5A.
The maximum DC resistance is 48mOhm.
The operating temperature range is -40°C to 105°C.
This inductor is designed for surface mounting.
It uses a drum core and is wirewound.
