| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
242 pcs
|
242 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Dielectric Withstanding Voltage | |
| Dissipation Factor | |
| Failure Rate | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Prop 65 | |
| Tape & Reel | |
| Temperature Coefficient | |
| Temperature Range | |
| Termination Style | |
| Tolerance |
The CK06BX153K is a ceramic capacitor from Kyocera AVX, part of the LDD Mil X7R C11015 series. It features a radial through-hole package with SnPb (leaded) terminations. The capacitor is qualified to MIL-PRF-11015, making it suitable for high-reliability applications.
Electrically, it offers 0.015 µF capacitance with ±10% tolerance and is rated at 100 VDC. The BX temperature coefficient ensures stable capacitance over the operating temperature range of -55°C to +125°C. Dissipation factor is 2.5% and insulation resistance is 66.7 GOhms. Dielectric withstanding voltage is 250 VDC.
Mechanically, the body measures 7.37 mm length, 7.37 mm height, and 2.29 mm thickness. Lead spacing is 5.08 mm, with a minimum lead length of 31.75 mm and lead diameter of 0.635 mm. The capacitor is supplied in bulk bags of 100 pieces.
Compliance: This capacitor is not RoHS compliant due to the SnPb termination. It carries a California Proposition 65 warning for cancer and reproductive harm. MSL is 1 (Unlimited) and REACH status is unaffected, though these are unverified low-confidence data points.
0.015 µF.
100 VDC.
BX.
±10%.
Radial through-hole with bulk packaging.
-55°C to +125°C.
5.08 mm.
