CI3103P1V00 The CviLux CI3103P1V00 is a 3-position wire-to-board header with a 2.54mm pitch. It features a through-hole mounting type and a friction lock fastening.
Mfr Part #:

CI3103P1V00

Available from 1 distributors
Mfr Name: Cvilux Corp
Cvilux Corp
The CviLux CI3103P1V00 is a 3-position wire-to-board header with a 2.54mm pitch. It features a through-hole mounting type and a friction lock fastening.
✓ Total Stock: 2,000 pcs
$ Price Range: $0.99

CI3103P1V00 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
2,000 pcs
On Request
2000 pcs On Request 1 On Request On Request 41004 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CI3103P1V00 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish - Mating
Contact Finish Thickness - Mating
Contact Length - Mating
Contact Length - Post
Contact Material
Contact Shape
Contact Type
Current Rating
Fastening Type
Halogen Free
Insulation Color
Insulation Height
Insulation Material
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch - Mating
Shrouding
Style
Termination
Voltage Rating
View Similar Products (0)

CI3103P1V00 Description

Short technical summary and product information.

The CviLux CI3103P1V00 is a 3-position header designed for wire-to-board connections. It offers a standard pitch of 2.54mm and a voltage rating of 250VAC with a current rating of 3A.



This header utilizes male pin contacts made of brass with a tin finish. It is designed for through-hole mounting and features a friction lock fastening mechanism. The insulation material is thermoplastic and halogen-free, with a natural color.



The operating temperature range for this component is -25°C to 85°C. It is shrouded with one wall for added protection. The flammability rating is UL94 V-0.



Key specifications include 3 loaded positions, 1 row, and solder termination. The overall contact length is 14.20mm, with a mating contact length of 7.49mm and a post contact length of 3.40mm. The insulation height is 11.50mm.

CI3103P1V00 Quick Information

Product Type: Header
Series: CI31
Canonical Name: CVILUX CORP CI3103P1V00 Header
Subcategory: Headers, Male Pins

CI3103P1V00 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

CI3103P1V00 Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

CI3103P1V00 Features

  • 3-position wire-to-board header.
  • 2.54mm pitch for reliable connections.
  • Rated for 250VAC and 3A current.
  • Through-hole mounting with friction lock.
  • UL94 V-0 flammability rating.

CI3103P1V00 Applications

  • Ideal for board-to-wire connections.
  • Suitable for general electronic assemblies.
  • Used in applications requiring secure mating.
  • Component for power and signal routing.

CI3103P1V00 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the voltage rating of the CI3103P1V00 header?

The voltage rating is 250VAC.

What is the current rating for the CI3103P1V00?

The current rating is 3A.

What is the operating temperature range for this header?

The operating temperature range is -25°C to 85°C.

What is the pitch of the CI3103P1V00 connector?

The pitch is 2.54mm.

How is the CI3103P1V00 mounted?

It is mounted using the through-hole method.

What is the flammability rating of the CI3103P1V00?

The flammability rating is UL94 V-0.

What is the standard package quantity for the CI3103P1V00?

The manufacturer standard package quantity is 1,000.
