| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The CI0105M1HR0-NH is a 5-position, single row, shrouded header from CviLux. It features a 2.00mm pitch and male pin contacts made of brass with a tin finish. The connector is designed for board-to-cable/wire applications and uses a surface mount, right angle mounting style with solder termination.
This header includes a 4-wall shroud with a detent lock fastening system for secure mating. The insulation is made of halogen-free polyamide (PA6T/Nylon 6T) in a natural color, rated UL94 V-0 for flammability. Solder retention features aid in reliable board attachment.
Electrical ratings are 2A current and 250VAC/DC voltage. The operating temperature range is -25°C to 105°C. The contact finish thickness is 120.0µin (3.05µm).
5 positions in a single row.
2.00mm (0.079 inches).
2A nominal.
250VAC/DC nominal.
Surface mount, right angle.
-25°C to 105°C.
Yes, it has a 4-wall shroud with a detent lock.
