CGA2B2X7R1H102KT0Y0F The TDK Corporation CGA2B2X7R1H102KT0Y0F is a 1nF ceramic capacitor with a 50V voltage rating and X7R temperature coefficient. It features a compact 0402 SMD footprint.
Mfr Part #:

CGA2B2X7R1H102KT0Y0F

Available from 1 distributors
Mfr Name: TDK Corporation
TDK Corporation
The TDK Corporation CGA2B2X7R1H102KT0Y0F is a 1nF ceramic capacitor with a 50V voltage rating and X7R temperature coefficient. It features a compact 0402 SMD footprint.
✓ Total Stock: 10,000 pcs
$ Price Range: $0.02

CGA2B2X7R1H102KT0Y0F Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
10,000 pcs
On Request
10000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CGA2B2X7R1H102KT0Y0F Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Capacitance
Mounting Type
Temperature Coefficient
Tolerance
Voltage
View Similar Products (0)

CGA2B2X7R1H102KT0Y0F Description

Short technical summary and product information.

The TDK Corporation CGA2B2X7R1H102KT0Y0F is a multilayer ceramic capacitor (MLCC) with a capacitance of 1nF and a voltage rating of 50V. It utilizes an X7R dielectric, providing ±15% capacitance stability over a wide temperature range of -55°C to +125°C. This makes it suitable for applications requiring a broader operating temperature.



The capacitor comes in a 0402 (1005 metric) SMD package, offering a compact, high-density footprint ideal for space-constrained designs such as smartphones, wireless charging modules, and IoT sensor modules. The ±10% tolerance ensures reliable performance in various electronic circuits.



Commonly applied in automotive electronics, consumer electronics, and wireless charging systems, this component is well-suited for end-products like ADAS radar/cameras, battery management systems (BMS), and on-board chargers (OBC). Its design considerations include the need for capacitance stability under varying thermal conditions, making it a robust choice for demanding applications.

CGA2B2X7R1H102KT0Y0F Quick Information

Product Type: Ceramic Capacitor
Series: CGA
Canonical Name: TDK Corporation CGA2B2X7R1H102KT0Y0F Ceramic Capacitor
Subcategory: Multilayer Ceramic Capacitor

CGA2B2X7R1H102KT0Y0F Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

CGA2B2X7R1H102KT0Y0F Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

CGA2B2X7R1H102KT0Y0F Features

  • Rated for 50V DC operation.
  • Features X7R dielectric for wide temperature stability.
  • Compact 0402 SMD footprint.
  • 1nF capacitance with ±10% tolerance.
  • Suitable for automotive and industrial use.

CGA2B2X7R1H102KT0Y0F Applications

  • Ideal for wireless charging modules.
  • Used in smartphones and IoT devices.
  • Suitable for automotive electronics.
  • Applied in ADAS radar and camera systems.
  • Common in battery management systems.

CGA2B2X7R1H102KT0Y0F FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance of the CGA2B2X7R1H102KT0Y0F?

1 nF.

What is the rated voltage of this capacitor?

50 V DC.

What is the temperature coefficient of the CGA2B2X7R1H102KT0Y0F?

X7R.

What is the tolerance of this capacitor?

±10%.

What is the package size?

0402 (1005 metric).

What is the operating temperature range for this capacitor?

-55°C to +125°C.

What is the capacitance stability over temperature?

±15% over -55°C to +125°C.
