CG223U035W4C
Cornell Dubilier Electronics (CDE)
The Cornell Dubilier CG223U035W4C is an aluminum electrolytic capacitor with a capacitance of 22000uF and a voltage rating of 35VDC. It features screw termination.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
45 pcs
|
45 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance | |
| Diameter | |
| Lead Spacing | |
| Length | |
| Termination Style |
This aluminum electrolytic capacitor from Cornell Dubilier (CDE), model CG223U035W4C, is designed for applications requiring significant capacitance and moderate voltage.
Key electrical specifications include a capacitance of 22000uF and a DC voltage rating of 35V. It features a low ESR of 11 mOhms and can handle a ripple current of 15.2A at 120Hz. The capacitor has a capacitance tolerance of -10% to +75%.
Mechanically, the component has a length of 105mm and a diameter of 63.5mm, with a lead spacing of 28.6mm. It is designed for screw termination.
Environmentally, the capacitor operates within a temperature range of -40C to +85C and has a rated life of 2000 hours. Its Moisture Sensitivity Level (MSL) is 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The capacitance is 22000 uF.
The DC voltage rating is 35 VDC.
The ESR is 11 mOhms.
The ripple current is 15.2 A at 120 Hz.
The operating temperature range is -40 C to +85 C.
The length is 105 mm.
The diameter is 63.5 mm.
