| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,000 pcs
|
5000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Power Rating | |
| Resistance | |
| Supplier Device Package | |
| Tape & Reel | |
| Temperature Coefficient | |
| Tolerance |
This KOA Speer Electronics CF1/4CT52R821J is a through-hole carbon film resistor designed for general-purpose applications. It offers a resistance value of 820 Ohms with a tolerance of ±5%, making it suitable for various circuit designs.
The resistor is rated for a power dissipation of 0.25W (1/4W) and can operate within a temperature range of -55°C to 155°C. Its axial package dimensions are 0.091 inches in diameter and 0.240 inches in length (2.30mm x 6.10mm), with a supplier device package also specified as Axial.
Key electrical characteristics include an absolute maximum working voltage of 250V and an absolute maximum overload voltage of 300V. The minimum dielectric withstanding voltage is 800V. The temperature coefficient is -450/+350ppm/°C.
This component is suitable for automatic machine insertion and offers stronger pulse resistance compared to chip resistors of the same type. Products with lead-free terminations meet EU RoHS and China RoHS requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 820 Ohms.
The tolerance is ±5%.
The power rating is 0.25W.
The operating temperature range is -55°C to 155°C.
The temperature coefficient is -450/+350ppm/°C.
The dimensions are 0.091" Dia x 0.240" L (2.30mm x 6.10mm).
The package type is Axial.
