| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | NO DC | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Resistance | |
| Supplier Device Package | |
| Temperature Coefficient | |
| Tolerance |
This KOA Speer Electronics CF1/4CT52R150J is a through-hole carbon film resistor designed for general-purpose applications. It features a resistance value of 15 Ohms with a tolerance of ±5% and a power rating of 1/4W (0.25W).
The resistor operates within a temperature range of -55°C to 155°C and has a temperature coefficient of -450/350ppm/°C. Its axial package dimensions are 0.091" in diameter and 0.240" in length (2.30mm x 6.10mm).
Suitable for automatic machine insertion, this component offers enhanced pulse resistance compared to chip resistors of the same type. Products with lead-free terminations meet EU RoHS and China RoHS requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 15 Ohms.
The tolerance is ±5%.
The power rating is 1/4W (0.25W).
The operating temperature range is -55°C to 155°C.
The temperature coefficient is -450/350ppm/°C.
The dimensions are 0.091" Dia x 0.240" L (2.30mm x 6.10mm).
The package type is Axial.
